Pb28 Change Order of Images in Photo Gallery with Drag and Drop using PHP AJAX
Drag and drop is a convenient UI feature for users when handling elements. In particular, while displaying images in a gallery and allowing the users to move around the images, drag and drop is the best option.
There are several plugins for gallery display with a reordering feature. We will implement this example with custom code using jQuery UI libraries.
In the Trello like project management example, we have seen how to reorder task cards based on their status. In this article, we will see how to apply the reordering feature to change the photo position in a gallery using PHP and jQuery.
I highly recommend you check that article to witness a seasoned drag-and-drop implementation.
The gallery images are dynamic from the database. Each photo card will be set with the draggable property to drag it to change its order. Once reordering is completed, the order will be updated in the database by clicking the Save button.
Code to Show Photo Gallery
This code contains HTML to display the gallery view to the user. The photos are fetched from the database and shown in this gallery. The PHP code for fetching database results and iterating the resultant photo arrays is embedded with the gallery view HTML.
<?php
require_once "db.php";
$sql = "SELECT * FROM tbl_images ORDER BY image_order ASC";
$result = $conn->query($sql);
$conn->close();
?>
<!doctype html>
<html>
<head>
<link rel="stylesheet" type="text/css" href="style.css" >
<title>Change Order of Images in Photo Gallery with Drag and Drop using PHP AJAX</title>
</head>
<body>
<div id="gallery">
<div id="image-container">
<h2>Change Order of Images in Photo Gallery with Drag and Drop using PHP AJAX</h2>
<div id="txtresponse" > </div>
<ul id="image-list" >
<?php
if ($result->num_rows > 0) {
while ($row = $result->fetch_assoc()) {
$imageId = $row['id'];
$imageName = $row['image_name'];
$imagePath = $row['image_path'];
echo '<li id="image_' . $imageId . '" >
<img src="' . $imagePath . '" alt="' . $imageName . '"></li>';
}
}
?>
</ul>
</div>
<div id="submit-container">
<input type='button' class="btn-submit" value='Submit' id='submit' />
</div>
</div>
</body>
</html>
Reorder with jQuery Drag and Drop
This script shows how to enable the drag and drop feature to change the photo position in the gallery UI. We can turn the gallery photo elements sortable by calling the jQuery UI sortable() method with the appropriate reference.
While sorting, the drop index is stored in a variable. This value will be used to construct the image id array based on conditions to optimize the update process with the limited images.
For example, If the sorting is made between the first three images, then only these three records must be updated instead of changing the entire image database.
After changing the image order, the Save button’s click event will send an AJAX request. In this request, a PHP code is called to update the changed order of multiple images in the DB.
<script src="vendor/jquery/jquery-3.2.1.min.js"></script>
<link rel="stylesheet" href="vendor/jquery/jquery-ui/jquery-ui.css">
<script src="vendor/jquery/jquery-ui/jquery-ui.js" type="text/javascript"></script>
<script>
$(document).ready(function () {
var dropIndex;
$("#image-list").sortable({
update: function(event, ui) {
dropIndex = ui.item.index();
}
});
$('#submit').click(function (e) {
var imageIdsArray = [];
$('#image-list li').each(function (index) {
if(index <= dropIndex) {
var id = $(this).attr('id');
var split_id = id.split("_");
imageIdsArray.push(split_id[1]);
}
});
$.ajax({
url: 'reorderUpdate.php',
type: 'post',
data: {imageIds: imageIdsArray},
success: function (response) {
$("#txtresponse").css('display', 'inline-block');
$("#txtresponse").text(response);
}
});
e.preventDefault();
});
});
</script>
PHP Code to Save Image Order in DataBase
This is the PHP code to save the image order in the database. This PHP file will be requested via AJAX by sending the image id references to be sorted. The array of image ids is received in this file and iterated to execute the database update.
<?php
require_once "db.php";
$imageIdsArray = $_POST['imageIds'];
$count = 1;
foreach ($imageIdsArray as $id) {
$sql = $conn->prepare("UPDATE tbl_images SET image_order=? WHERE id=?");
$imageOrder = $count;
$imageId = $id;
$sql->bind_param("ii", $imageOrder, $imageId);
if ($sql->execute()) {
$response = 'Images order is updated';
} else {
$response = 'Problem in Changing the Image Order';
}
$count ++;
}
echo $response;
exit;
?>
Database Script
The gallery images are stored in the database table  tbl_images. The following database script shows the database table’s create statement and the data dump. Import this script to setup database to run this example in your PHP environment.
--
-- Table structure for table `tbl_images`
--
CREATE TABLE `tbl_images` (
`id` int(11) NOT NULL,
`image_name` varchar(200) NOT NULL,
`image_path` varchar(50) NOT NULL,
`image_order` int(2) NOT NULL,
`date` timestamp NOT NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP
) ENGINE=InnoDB DEFAULT CHARSET=utf8;
--
-- Dumping data for table `tbl_images`
--
INSERT INTO `tbl_images` (`id`, `image_name`, `image_path`, `image_order`, `date`) VALUES
(2, 'Image6', 'images/image6.jpeg', 3, '2018-09-16 10:46:21'),
(3, 'Image1', 'images/image1.jpeg', 5, '2018-09-16 10:45:34'),
(4, 'Image2', 'images/image2.jpeg', 4, '2018-09-16 10:45:34'),
(5, 'Image3', 'images/image3.jpeg', 6, '2018-09-16 10:45:34'),
(6, 'Image4', 'images/image4.jpeg', 2, '2018-09-16 10:45:34'),
(9, 'Image5', 'images/image5.jpg', 1, '2018-09-16 10:45:34');
ALTER TABLE `tbl_images`
ADD PRIMARY KEY (`id`);
--
-- AUTO_INCREMENT for dumped tables
--
--
-- AUTO_INCREMENT for table `tbl_images`
--
ALTER TABLE `tbl_images`
MODIFY `id` int(11) NOT NULL AUTO_INCREMENT, AUTO_INCREMENT=10;
COMMIT;
